high vacuum oil purifier machinery

FOB Reference Price:Get Latest Price
$6,200.00 - $25,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
RZL-50 70 100 150 200
Usage:
Lubricant Oil
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 8 Negotiable
Report Suspicious Activity
Overview
Quick Details
Applicable Industries:
Manufacturing Plant
Condition:
New
Place of Origin:
Chongqing, China
Brand Name:
junneng
Voltage:
380v/50hz
Warranty:
1yeas
After-sales Service Provided:
Field installation, commissioning and training, Engineers available to service machinery overseas
Water content in oiWater content in oil:
100ppm
Vacuum Range:
-0.06~ -0.095mpa
Supply Ability
Supply Ability:
20 Set/Sets per Month
Packaging & Delivery
Packaging Details
Wooden box packaging, to meet the export transport requirements.
Port
FOB CHONGQING
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 8 To be negotiated
Product Category
Product Description

high vacuum oil purifier machinery

After processing of oil, can reach new oil standards, reuse.

Product details

Water content in oiWater content in oil≤100ppm
Vacuum Range-0.06~ -0.095mpa
Product Keywordshigh vacuum oil purifier oil deodorizing machinery

Features:

RZL series high vacuum oil purifier machinery

RZL series oil purifiers are suitable especially for purifying and restoring hydraulic oil, machine oil, coolant oil and various other lubrication oil this kind of oil purifier can purify contaminated lubrication in which much water, gas and many impurities exist. RZL series can rapidly remove water, gas, particular matters and impurities from lubrication oil and improve properties of lubricating oil so as to greatly extend lifetime of machinery which has lubrication system.

It is especially suitable for industries including petroleum, chemical, mine, metallurgy, power, traffic, mechanical manufacture and railway for the recovery and purification of various lubricating oil such as hydraulic oil, mechanical oil, cooling oil, refrigerating oil, gear oil, gasoline engine oil, diesel oil and heat treatment oil.



Characteristics:

1) Perfect capacity of removing impurities. The special filters made by JunNeng are made of special materials which can effectively and rapidly eliminate various impurities, water and gas.

2) Automatic reverses flushing ability, which automatically cleans the mass impurities withheld by the purifier.

3) Advanced medium heating absorption and condensation system

4) Pressure protection, auto heating temperature control, and device of auto separation of condensate water, easy to handle, safe and reliable.

5) Top quality purification material, large capacity of handling impurity, corrosion-proof, high temperature resistant, good mechanical strength, high precision of impurity removal and long lifetime.

6) Unique water/gas removal system, which adopts stereo-evaporation technology, multi-oil water separation technology, enabling fast removal of water, gas and impurity in oil.

7) Imported parts are used for all electric system, which ensures operation of the equipment with high performance

8) Lowly noisy oil pump is specially made..



Technical Parameters



Name

Unit

RZL-30

RZL-50

RZL-100

RZL-150

RZL-200

RZL-250

Flow

L/min

30

50

100

150

200

250

Vacuum Range

Mpa

-0.06~ -0.095

Temperature Range

60~80

Oil pump pressure

Mpa

≤0.4

Power Supply



50HZ  380V

Total Power

kw

32

42

68

89

130

180

Cleanliness

NAS

≤NAS 6 (NAS1638 )

Water content in oil

ppm

≤100

Mechanical impurity

%

no

Working Noise

db(A)

65~85

inlet (outlet) diameter

mm

25

32

42

50

60

60

dimension

mm

L

1600

1800

2450

2600

2800

2850

W

900

1000

1400

1500

1600

1600

H

1600

1800

2100

2300

2400

2400



Dimension and weight will be changed with changing the technical specification.



Quality assurance:

1, product quality assurance for one year, any non-artificial damage, shall be the responsibility of the manufacturer.
2, the manufacturers provide overseas engineers, door-to-door guidance, installation and use.




Packaging & Shipping

PACKAGE:

Wooden packing,Meet the export transport requirements

DELIVERY TIME:

7-10 days after confirming order,detail delivery date should be decided according to
production season and order quantity.

Certifications

CERTIFICATE



All our products are passed the inspection standards included SGS,BV,CE with 100% quality.
