ZL high efficient insulating oil vacuum filter

FOB Reference Price:Get Latest Price
$3,305.10 - $15,807.00 / Set | 1 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Place of Origin:
Chongqing, China
Brand Name:
Junneng ZL High-Efficient Vacuum Oil Purifier
Model Number:
ZL High-Efficient Vacuum Oil Purifier
Weight:
1200kg
Certification:
ISO9001
Structure:
Vacuum
Type:
vacuum oil purifier
Dimension(L*W*H):
2.4*1.5*2.1m
Power(W):
according to your flow rate
Usage:
insulation oil filter
oil pump pressure:
0.05-0.3 mpa
gas amount of the oil:
lower than 0.1%
precision of the oil:
lower than 5um
water amount of the oil:
lower than 5ppm
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
1 year
Supply Ability
Supply Ability:
50 Set/Sets per Month
Packaging & Delivery
Packaging Details
ZL High-Efficient Vacuum Oil Purifier is suitable for firm wooden cases,suitable for long distance ocean freight
Port
chongqing port
Lead Time :
ZL High-Efficient Vacuum Oil Purifier is within 7 days

ZL high efficient insulating oil vacuum filter





ZL series of high efficient vacuum oil purifier is casehardened product of electric power industry. It is researched according to the newest drying theory and precisely filtering technology for disposing unqualified insulation oil of electric department and other enterprises. It is ideal equipment used in drying and making vacuum oil injection.

---Usage:

It is widely used in power plant, hydropower station, electric power company, metallurgy, petrifaction, railroad, etc. It can purify unqualified transformer oil, mutual-inductor oil, switch oil and capacitor oil, also rapidly dehydrate, degasify and purify oil. Meanwhile, it also has the function of drying electric machine and injecting oil to electric equipment.

---Characteristics:

A: Super dehydration and degasification system. We adopt large cubage to rapidly separate water and gas from oil.

B: Reliable heating system to ensure heating and stable oil temperature.

C: Precise filtration system adopts high-grade filtration materials which has advantages of good mechanical intensity, multi-level filtration, gradually intensive and high filtration precision system.

ZL 1.jpg

D: Advanced pressure protection device and infrared control system can avoid the influence of wrong operation.

E: Integration has chain security protection. It can automatically control the oil pressure and oil level.

F: This machine can be used with BZ series of transformer oil discoloring device together to add the function of acid-removing, discoloring, uncombined carbon removing, and reducing damage.





Technical Parameters



Model

ZL-20

ZL-30

ZL-50

ZL-70

ZL-100

ZL-150

ZL-200

Rated Flow( L/min)

20

30

50

70

100

150

200

Vacuum Range

-0.05— -0.099Mpa

Temperature Range

60—80 Degree centigrade

Oil pump pressure

0.05-0.3Mpa

Total Power (kw)

25

25

32

32

42

50

60

Breakdown Voltage

≥55kv

Power

50HZ   380V

Working Noise

65—80 db(A)

Cleanliness

NAS 6 (NAS1638)

Water content in oil

≤5ppm

Gas content in oil

≤0.1%

Filter precision

≤5um

Inlet (outlet) diameter(mm)

33

33

48

48

60

60

60



Dimension(mm)

L

1100

1100

1200

1250

1300

1400

1550

W

700

700

800

850

900

1000

1200

H

1300

1350

1400

1450

1520

1600

1800



Attention: Dimension and weight will be changed with changing the technical specification.
